ATN Odin 6 640×480 Multi-Function Thermal Monocular with Laser Rangefinder
(1–8× Magnification & 1,859-yd Detection Range)
Multi-Function Thermal Performance in a Compact Platform
The ATN Odin 6 MFT 640 LRF Thermal Monocular delivers advanced thermal imaging combined with precision rangefinding in a compact, multi-role platform. Designed for hunters, professionals, and tactical users, this system provides the flexibility to operate as a handheld monocular, helmet-mounted optic, clip-on device, or dedicated weapon sight.
Built on ATN’s 6th Generation thermal engine, the Odin 6 MFT 640 LRF features a 640×480 thermal sensor with a 12µm pixel pitch and ≤15 mK NETD sensitivity, delivering sharp image detail, improved contrast, and reliable detection in low-visibility environments such as fog, brush, and total darkness.
The 25 mm germanium lens paired with a 1–8× magnification range allows for both wide-area scanning and precise target identification. With a detection range of 1700 meters (1,859 yards), this model is well-suited for mid- to long-range observation.
The integrated laser rangefinder provides accurate distance measurements up to 1000 meters with ±1 meter accuracy, enabling better situational awareness and improved shot placement.
ATN SharpIR technology enhances image clarity in real time by refining edges and boosting contrast. The high-resolution 1280×1024 OLED display delivers crisp visuals with smooth motion tracking for extended observation sessions.
With onboard video and audio recording, Recoil Activated Video (RAV), and 64 GB internal storage, users can capture and review footage directly on the device. USB-C connectivity allows for data transfer and external power support.
Built with a rugged magnesium alloy housing and powered by either a rechargeable 18650 battery or CR123A, the Odin 6 MFT 640 LRF is designed for demanding environments with IP67 weather resistance and up to 8 hours of runtime.
ATN Odin 6 MFT 640 LRF Features:
- 640×480 thermal sensor
- ≤15 mK NETD sensitivity
- 1–8× magnification
- Detection range 1700 m / 1,859 yd
- 25 mm germanium lens
- 1280×1024 OLED display
- ATN SharpIR image enhancement
- Built-in laser rangefinder (1000 m)
- Multi-function design (monocular, clip-on, helmet, weapon sight)
- 64 GB internal storage
- Video and audio recording
- Recoil Activated Video (RAV)
- USB Type-C connectivity
- Dual battery compatibility (18650 / CR123A)
- Magnesium alloy housing
Built For:
- Predator and hog hunting
- Helmet-mounted and handheld observation
- Clip-on or weapon-mounted use
- Law enforcement and tactical operations
- Search and rescue applications
ATN Odin 6 MFT 640 LRF Specifications:
| Odin 6 MFT 640 LRF — TIMFOD6625LRF | Specifications |
|---|---|
| Quick Specs | Sensor: 640 × 480 • NETD: ≤15 mK • Display: 1280 × 1024 • Detection: 1700 m • Objective: 25 mm • Storage: 64 GB Internal • Weight: 0.88 lb |
| OPERATION MODES | |
| Operation Modes | Clip-On, Weapon Sight, Helmet Monocular, Handheld Monocular |
| OPTICS & SENSOR | |
| Detector Type | 12 μm VOx Uncooled Focal Plane Array |
| Sensor Resolution | 640 × 480 |
| Thermal Sensitivity (NETD) | ≤15 mK |
| Refresh Rate | 50 Hz |
| SharpIR© | Yes |
| Non-Uniformity Correction (NUC) | Auto / Manual |
| Lens | 25 mm Germanium; F/1.0 |
| Field of View (H × V) | 17.5° × 13.2° |
| Focus Mechanism | Manual Focus Controlled by Lens Adjustment |
| Magnification | 1–8× |
| Digital Zoom | 1×, 2×, 4×, 8× |
| Detection Range | 1700 m |
| RANGEFINDING & TARGETING | |
| Built-in Laser Rangefinder (LRF) | Yes |
| LRF Range | 1000 m |
| LRF Accuracy | ±1 m |
| LRF Laser Specs | 905 nm, Class 1 (Eye Safe) |
| Ballistic Calculator | Yes |
| Automatic Range Finder | Yes |
| Ballistic Profiles | 9 Customizable Profiles |
| Reticle Types | Ballistic Reticle Optimized for 5.56 × 45 mm and 7.62 × 51 mm; User-Defined Reticles Supported |
| Reticle Styles | 7 Styles |
| DISPLAY & VIEWING | |
| Display Type | 0.37″ OLED |
| Display Resolution | 1280 × 1024 HD |
| Picture-in-Picture (PIP) | Yes |
| Color Palettes | Multiple |
| Eye Relief | Unlimited |
| Diopter Range | -3 to +3 D |
| NV Retention Mode | Yes — Special Mode for Retaining Natural Night Vision Capability |
| Customizable User Interface | Yes |
| RECORDING & CONNECTIVITY | |
| Video / Audio Recording | Yes |
| Recoil Activated Video (RAV) | Yes |
| Media Output | USB Type-C — Data Transfer & Power Supply |
| Internal Storage Capacity | 64 GB |
| SMART FEATURES | |
| Geomagnetic Sensor + Gyroscope | Yes |
| Hot Point Tracking | Yes |
| Standby / Sleep Mode | Yes — Includes Shake-to-Wake |
| Startup Time | ≤5 Seconds |
| POWER | |
| Battery Type | 1 × 18650 or 1 × CR123 or External USB Type-C (5 VDC) |
| Battery Life | Approximately 8 Hours with 18650 / Approximately 1 Hour with CR123 |
| External Power Supply | Yes — USB Type-C (5 VDC / 2A) |
| DESIGN & DURABILITY | |
| Material | Magnesium Alloy |
| Mounting | Wilcox NVG Shoe Interfaces / Picatinny (MIL-STD-1913) Rail Mount |
| Button Configuration | 5 Functional Buttons Including Power |
| Weight | 400 g / 0.88 lb — Without Battery or Eyecup |
| Dimensions (L × W × H) | 100 × 75 × 60 mm (3.94 × 2.95 × 2.36 in) |
| Max Recoil Rating | 4500 J / 800g Over 0.3 ms |
| Operating Temperature | -46°C to 49°C (-51°F to 120°F) |
| Waterproof / IP Rating | IP67 |
